Observation Camera

Thermal Imaging Camera (13)

Observation Camera

Overview

In industrial sites, numerous processes are carried out automatically or manually. These processes are continuously monitored and controlled using the latest technology. Additionally, multiple CCTV cameras are installed to ensure safety and surveillance. This system is particularly useful for detecting fires or emergency situations by integrating specialized cameras into ducts, pipes, or furnaces.

Key Features

  • Auto Retraction Function (Automatic forward and reverse)
  • Easy Maintenance with a built-in shut-off valve
  • Special Dust Cut-Off Device for enhanced durability
  • Customizable Design to fit specific site conditions
  • High-Temperature Resistance : Operates without cooling at 1000℃ for up to 10 minutes

Specifications

Camera
  • 2.5 Megapixel 1/3-inch CMOS Sensor
  • 3G/HD-SDI (BNC) & HDMI output on the rear panel
Lens Tube
  • Diameter : 32mm
  • Length : Customizable based on site conditions
Retraction Device
  • Minimum 4 bar instrument air required
  • Length : Customizable based on site conditions
Control Box
Dimensions 600W x 500H x 200D mm
Power Supply 110 − 240 VAC, 50 − 60 Hz, 3 AMP
Air Consumption 0.8 m³/min at 4 bar
